Cassandra on Kubernetes Part 1

Apache Cassandra Lunch #41: Cassandra on Kubernetes – Docker/Kubernetes/Helm Part 1

In Apache Cassandra Lunch #41: Apache Cassandra Lunch #41: Cassandra on Kubernetes – Docker/Kubernetes/Helm Part 1, we discuss Cassandra on Kubernetes and give an introduction to Docker, Kubernetes, and Helm. The live recording of Cassandra Lunch, which includes a more in-depth discussion and a demo, is embedded below in case you were not able to attend live. If you would like to attend Apache Cassandra Lunch live, it is hosted every Wednesday at 12 PM EST. Register here now!

In Apache Cassandra Lunch #41: Apache Cassandra Lunch #41: Cassandra on Kubernetes – Docker/Kubernetes/Helm Part 1, we discuss Cassandra on Kubernetes and introduce containerization technologies and how they work.

Containers : “Get with the program”

  • Docker – One “Dockerfile” becomes an Image which runs as one container on a node / host.
  • Docker-Compose – Can run multiple containers on a node / host in as a composition. (Kompose)
  • Docker Swarm – Can run docker-compose at scale on many node / hosts.
  • Mesosphere/DCOS – Mesos, grand daddy of containerization adopted Docker, and Kubernetes
  • Kubernetes – Basically everyone who does anything uses Kubernetes to deploy big applications.
Docker vs VM
Docker vs VM
Docker Architecture
Docker Architecture
Docker Images Example
Docker Images Example
Docker Processes
Docker Processes

Kubernetes General Architecture

  • Nodes (minimum of 3 physical nodes)
    • Master Nodes / Control Plane (at least 1)
      • A master node is a node which controls and manages a set of worker nodes (workloads runtime) and resembles a cluster in Kubernetes. … All external communication to the cluster is via the API-Server. Kube-Controller-Manager, which runs a set of controllers for the running cluster.
      • Whenever master node under kubernetes fails, the cluster still remains in an operational mode. It doesn’t affect pod creation or service member changes. If worker node fails, master stops receiving updates from worker node
      • High availability / multi-master nodes use a load balancer to manage the API server which serves both the clients and the worker nodes
Kubernetes Cluster
Kubernetes Cluster
  • Worker Nodes (at least 2)
    • The worker nodes run the workloads. The worker node contains kubelet and kube-proxy that both connects to the pods within the docker. … A kubelet takes information from the master node and ensures that any pods assigned to it are running and configured in the desired state. All Kubernetes nodes must have a kubelet.
Kubernetes kubelet
Kubernetes kubelet
  • Containers
    • By themselves, don’t do much in Kubernetes.
    • Need to make it part of a Pod.
Container Example
Container Example
  • Pods
    • Pods are the smallest, most basic deployable objects in Kubernetes. A Pod represents a single instance of a running process in your cluster. Pods contain one or more containers, such as Docker containers. When a Pod runs multiple containers, the containers are managed as a single entity and share the Pod’s resources.
Example of Pods
Example of Pods
  • Workloads
    • Deployments / ReplicaSet (Stateless)
      • Node Express
      • Python Flask
      • Java Springboot
    • StatefulSets (State)
      • MySQL
      • Cassandra
      • Leverages “PersistentVolume” that is managed as a resource.
    • DaemonSet
      • “Sidecar” local to that node
      • Monitoring / Management
    • Job / CronJob
      • Tasks that run and stop.
      • Job – one-off tasks
      • CronJob – recurring tasks

Helm Charts

  • Components
    • The client (CLI), which lives on your local workstation.
    • The server (Tiller), which lives on the Kubernetes cluster to execute what’s needed.
  • Concepts
    • Chart: A package of pre-configured Kubernetes resources.
    • Release: A specific instance of a chart which has been deployed to the cluster using Helm.
    • Repository: A group of published charts which can be made available to others.
  • Why?
    • Boosts productivity
    • Reduces duplication & complexity
    • Smoothens the learning curve
    • Simplifies deployments
Example Architecture
Example Architecture
Example Architecture 2
Example Architecture 2

  • Operators
    • The Operator pattern aims to capture the key aim of a human operator who is managing a service or set of services. Human operators who look after specific applications and services have deep knowledge of how the system ought to behave, how to deploy it, and how to react if there are problems.
    • Tasks
      • deploying an application on demand
      • taking and restoring backups of that application’s state
      • handling upgrades of the application code alongside related changes such as database schemas or extra configuration settings
      • publishing a Service to applications that don’t support Kubernetes APIs to discover them
      • simulating failure in all or part of your cluster to test its resilience
      • choosing a leader for a distributed application without an internal member election process
    • Why?
      • Robots are better at doing repetitive tasks
      • Simplifies the overall complexity of an operation into a few configurable components
      • Makes pattern reuse possible
    • How to make Operators? (via Operator SDK)
      • Helm
      • Go
      • Java
      • Ansible
Example K8S cluster
Example K8S cluster
Example Spark and Kubernetes Cluster
Example Spark and Kubernetes Architecture
Example Cassandra Kubernetes Cluster
Example Cassandra Kubernetes Cluster
Example Cassandra and Kubernetes Architecture
Example Cassandra and Kubernetes Architecture
